Engine specification

Cylinder displacement                                                  65.1cm

Power output                                                                3.4 kw

Idling sped                                                                    2700rpm

Maximum power speed                                                9000rpm

Cylinder bore                                                               48mm

Cylinder stroke                                                             36mm

Ignition system                                                             SEM AM50

Ignition module air gap                                                0.3mm

Spark plug                                                                   Champion RCJ7Y, NGK BPMR7A

Electrode gap                                                              0.5mm

Carburetor model name                                              C3M-EL2B

Fuel tank volume                                                         0.77 lit

Oil tank volume                                                            0.4 lit

Oil pump type                                                               Adjustable flow

Oil pump capacity                                                        4-20ml/min

Cutting equipment

Chain pitch                                                                   3/8"

Recommended bar length, min-max                           38.70cm

Chain speed at max power                                          20.7m/s

Bar mount                                                                    Large

Emission,vibration & noise data

Equivalent vibration level (ahv.eq) front/rear handle    3.6/3.5m/s2

Sound pressure level at operators ear                        102.5dB(A)

Sound power level, guaranteed (LWA)                        112dB(A)

Overall dimensions

Weight (excl.cutting equipment)                                   6kg

Adjustable oil pump

Adjustable oil pump makes it easy to set the chain lubrication according to your needs.



Air Injection

Centrifugal air cleaning system for reduced wear and longer operating time between filter cleanings.

Ergonomic grip

Angled front handle for better grip and natural working position.



Low Vibe

Effective anti-vibration dampeners absorb vibration, sparing the user's arms and hands.

Magnesium crankcase

Sturdily built crankcase withstands high RPM's and tough professional use, ensuring a long service life.

Quick-release air filter

Facilitates cleaning and replacement of the air filter.

Side-mounted chain tensioner

Side-mounted chain tensioner makes chain adjustment quick and easy.
