Engine Specification

Cylinder displacement                                      45.7cc

Power Output                                                    2.8hp

Maximum Power speed                                    9600rpm

Maximum recommended engine speed           13000rpm

Idling speed                                                     2700rpm

Spark plug                                                         Champion RCJ7Y, NGK BPMR7A

Electrode gap                                                    0.02"

Lubricants

Oil tank volume                                                0.55 US pint

Oil Pump type                                                   Fixed flow

Oil Pump Capacity                                            9.9ml/min

Vibration & Noise Data

Equivalent vibration level  (ahv,eq)                   front/1.9/2.6m/s2 rear handle

Sound pressure level at operators ear             103.3dB(A)

Sound pressure level,guaranteed (LWA)          114dB(A)

Cutting Equipment

Chain pitch                                                        .325"

Recommended bar length, min-max                 13" -20"

Chain speed at max power                               56.89fts

Overall dimensions

Weight(excl.cutting equip.)                               10.8lbs

Air Injection

Centrifugal air cleaining system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and

improved engine life.

Combined choke/stop control

Allow for easier starting and reduces the risk of engine flooding.

Easy to start

Combined start/stop switch and fuel pump make the saw very easy to start.

Felling Marks

Distinct marks for better felling precision.

Quick-release air filter

Facilitates cleaning and replacement of the air filter.

Side-mounted chain tensioner

Easier access to chain tensioning device.
