Spec's
Air Injection
Choke/stop
Ergonomic
Felling
Quick-release
Snap-lock
Three-piece
X-Torq
Engine Specification
Cylinder displacement 50.2cc
Power output 3.2hp
Maximum power speed 9600rpm
Idling Speed 2700rpm
Spark plug NGK BPMR7A
Electrode gap 0.02"
Lubricants
Oil tank volume 0.55 US pint
Oil pump volume Fixed flow
Oil pump capacity 9-9ml/min
Vibration & Noise data
Equivalent vibration level (ahv,eq) front/2.3/2.7m/s2 rear handle
Sound pressure level at operator's ear 103.5dB(A)
Sound power level,guaranteed (LWA) 115 dB(A)
Cutting Equipment
Chain pitch .325"
Recommended bar length, min-max 13"-20"
Chain speed at max power 56.89fts
Overall Dimensions
Weight (excl.cutting equipment) 11.33lbs
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleaning and imporved engine life.
Combined choke/stop control
Allows for easier starting and reduces the risk of engine flooding.
Ergonomic rear handle
Increased comfort with soft inlay, ergonomic trigger and asymmetrical handle.
Felling Marks
Distinct marks for better felling
precision.
Quick-release air filter
Facilitates cleaning and replacement of the air filter.
Snap-lock cylinder cover
Saves time when changing spark plugs and cleaning.
Three piece crankshaft
Forged three-piece crankshaft for maximum durability for the toughest applications.
X-Torq
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world's most stringent environmental regulations.
