Spec's
Air Inject.
Choke/stop
Front handle
Low Vibe
Quick-Release
Side-mounted
Three-piece
X-Torq
Engine Specification
Cylinder displacement 55.5cc
Power output 3.5hp
Maximum power speed 9000rpm
Maximum recommended engine speed 13300rpm
Idling speed 2700rpm
Spark plug Champion RCJ7Y, NGK BPMR7A
Electrode gap 0.02"
Lubricants
Oil tank volume 0.7 US pint
Oil pump type Adjustable flow
Oil pump capacity 6-17ml/min
Vibration & noise data
Equivalent vibration level (ahv,eq) front/3.4/4.5m/s2 rear handle
Sound pressure level at operators ear 104dB(A)
Sound power level,guaranteed (LWA) 113dB(A)
Cutting Equipment
Chain pitch . 325"/3/8"
Recommended bar length,min-max 13"-20"
Chain speed at max power 65.62fts
Overall dimensions
Weight (excl. cutting equipment) 12.8lbs
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
Combined choke/stop control
Allows for easier starting and reduces the risk of engine flooding.
Front handle ergonomics
Better grip and 7" offset handle reduces fatigue.
Low Vibe
System designed to reduce vibration levels to the operator, which lessens fatigue.
Quick-release air filter
Facilitates cleaning and replacement of the air filter.
Side-mounted chain tensioner
Easier access to chain tensioning device.
Three-piece crankshaft
Forged three-piece crankshaft for maximum durability for the toughest applications.
X-Torq
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world's most stringent environmental regulations.
