YTH 22V46 Lawn Tractor

#960-4301-61

OUR

PRICE

$1,759.00

Husqvarna's yard tractors offer premium performance with quality results. Their compact size makes them easy to maneuver and require less space for storage. Features such as fender-mounted cutting height adjustment, adjustable seat and an ergonomic steering wheel make these tractors simple and comfortable to operate. All tractors feature hydrostatic transmissions for smooth, variable forward and reverse speed. Air Induction mowing technology improves airflow within the deck, ensuring a clean, consistent cut every time. For added versatility, all models can be equipped with a range of towable accessories and mulch kit for effective lawn fertilization.

Spec's

Air Induction

Ergonomic

Briggs

Deck Wash

Fender

Hour meter

Pedal

Step through

Traveling

Engine name                                           Intek

Power                                                        22hp

Cylinder displacement                            656cc

Cylinders                                                         2

Engine cooling                                             Air

Generator                                                   15A

Battery                                             12 V 28Ah

Fuel Type                                            Gasoline

Fuel tank volume(with reserve)             3 gal.

Fuel tank location                                   Front

Engine lubrication type   Pressure w/Oilfilter

Oil filter                                                       Yes

Transmission type                         Hydrostatic

Transmission manufacturer            Tuff Torq

Drive method                           Pedal-operated

Speed forward, min-max                0-5.2mph

Speed reverse, min-max                  0-2.9mph

Cutting width                                              46"

Cutting deck type                               Stamped

Cutting deck material                               Steel

Cutting methods         Collection/Mulch/Side

Cutting height,min-max (approx.)       1.5-4"

Cutting height adjustment                    Notch

Cutting height steps                                       6

Cutting height adjuster        Fender-mounted

Blade engagement                               Manual

Blades                                                              2

Blade type                               Hi Performance

Anti-scalp wheels                                           2

Powder-coated cutting deck                      Yes

Deck Wash Port                                          Yes

Seat back height                                       High

Seat material                                            Vinyl

Engine manufacturer           Briggs &Stratton

Steering wheel type         Deluxe Overmolded

Front-End Protection                        Optional

Hour meter                                                 Yes

Collector                       Available as accessory

BioClip Kit/plate          Available as accessory

Tire size, front                                      15x6-6"

Tire size, rear                                       20x8-8"

Turning radius, min                                    16"

Wheelbase                                                   48"

Base machine, length                              69.2"

Base machine,width(chute down)          56.7"

Base machine,width(chute up)                 48"

Base machine, height                              41.4"

Weight                                                   434lbs

Warranty                                 3 Year Limited

                     5 Year Limited Chassis and Axle

Air Induction Mowing Technology

Air is drawn from the top and bottom of the deck, improving grass lift and delivering a superior cut.

Ergonomic Steering Wheel

Comfortable steering wheel, angled for optimal drivers position.

Ergonomic Seats

15" High back seats are adjustable for comfort.

Briggs & Stratton Intek V-Twin

Two-cylinder engine provides longer life for the most demanding jobs. Features full pressure lubrication, an advanced debris management system, and a mechanical compression release for reliable starting.

Deck Wash Port

Connect your water hose to the port to clean the underside of your deck.

Fender-mounted cutting height adjustment

Easy accesible cutting height adjustment for improved ergonomics. The spring-assisted cutting deck makes adjustment easier.

Hour meter with service minder

Indicates when it's time to service your mower.

Pedal-operated hydrostatic transmission

Speed and direction are managed by pedals, which lets you keep both hands on the steering wheel, for optimum driving control.

Step-through

Ensures comfortable and easy mounting and dismounting.

Traveling connection

Traveling connection requires less energy when working and can be connected in a grass or forest postion.
